This unit machine is special design for packaging various vegetable like White radish, cucumber, lettuce, cabbage in to plastic bag .The whole machine have the function of automatic product feeding ,weighing ,film bag forming ,bag sealing ,Including date coding ,bag counting .The finished bag is output from conveyor machine which no need manual collect the bag and avoid the bag polluting .
Application:
It is suitable for quantitative weighing of large target weight or large volume materials such as vegetable salad, fruit salad, potatoes, onions, tomatoes, cherry tomatoes and other vegetables and fruits.
Caractéristiques:
- Special load cell with high precision and high standard.
- Program recovery function can reduce operation failures, support multi-segment weight calibration.
- No products auto pause function can improve weighing stability and accuracy.
- Linear amplitude can be adjusted independently, can make the feeding more uniform.
- 15 languages available for global markets.
- 100 programs capacity can meet various weighing requirement, user-friendly help menu in touch screen contributes to easy operation.
Introduction :
Cette machine peut automatiquement réaliser des fonctions de fabrication de sacs, de remplissage, de scellage, d'impression, de découpe, etc. Cette machine peut atteindre automatiquement le sac formant le remplissage et le scellage.
Cette machine d'emballage adopte un servomoteur d'importation pour l'alimentation du film et l'interface homme-machine utilise un écran tactile avancé. Opération plus simple et plus pratique. Tous les composants adoptent une marque de renommée internationale, le PLC est SIEMENS, le servomoteur est PANASONIC, l'écran tactile est SIEMENS, le cylindre et la vanne d'air sont SMC. les pièces en contact avec le matériau, l'armoire de commande, le cadre principal sont en acier inoxydable304
Paramètres techniques:
| Modèle | ZL780 |
| Forming bag type | Pillow bag/gusseted bag |
| Longueur de sac | 150-480mm by secondary film pulling the bag length can be longer |
| Largeur du sac | 120-375mm(Side width +front width ) |
| Largeur du film | ≤780mm |
| Bag forming speed | 5-15bag/min |
| Air source consumption | 0.8MPa 0.45m3/min |
| Max outer diameter of reel | ¢400mm |
| Core inner dia | ¢75mm |
| Puissance | 6KW 380V±10% 50Hz |
| Taille de la machine | 1650*1500*1750mm |
| Poids de la machine | 650 kg |
